    ZP800-O3 0-50ppm Circulation Type Ozone Gas Detector Electrochemical Principle For Pipelines

    Ask Lasest Price
    Brand Name : Zetron
    Model Number : ZP800-O3
    Certification : CE, ISO13485, ISO9001
    Payment Terms : T/T, L/C, Western Union, MoneyGram
    Supply Ability : 1000 set/month
    Delivery Time : 3-7 days
    • Product Details
    • Company Profile

    ZP800-O3 0-50ppm Circulation Type Ozone Gas Detector Electrochemical Principle For Pipelines

    ZP800-O3 Ozone Gas Detector

    OVERVIEW

    Adopt British sensor, can be non-contact operation and maintenance instrument Compatible with various control alarms, PLC, DCS and other control systems, remote monitoring can be achieved, explosion-proof design, fast, reliable, stable; Ex d II CT6 full software automatic calibration function, the machine has a total of three standard keys to achieve a single person single-point field maintenance.


    FEATURE

    • Monitor ozone gas concentration in the environment or in the pipeline
    • Full software automatic calibration function, zero calibration function, make gas monitoring more accurate and reliable
    • With temperature compensation, it can realize the compensation of gas concentration under different temperature environment
    • One or two switching signals can be output to drive external devices such as exhaust fans or solenoid valves
    • Working voltage: 12-36V DC power supply

    PARAMETER

    Detecting gasOzone concentration in air
    Detection principleelectrochemical
    Detection methodCirculation type
    Measuring range0-50ppm
    Resolution0.01ppm(0-50ppm);
    Accuracy±3%FS
    Display modeLiquid crystal display
    Response time≤ 30 seconds
    Recovery time≤60 seconds
    Explosion-proof markExdⅡCT6
    Explosion-proof connection thread3/4" NPT
    Signal output4~20mA 2-wire standard current (load 1500 ohms)
    Transmission distance1100m (Rvv0.75 square mm shielded cable)
    Operating temperature-20℃~+50℃
    Relative humidity10% ~ 95% RH (non-condensing)
    Power source24VDC±12VDC
    Weightabout 1.5Kg

    Tag: Exhaust ozone detector, Ozone detector, Ozone concentration online monitor, Ozone generator manufacturer, Tabletop ozone analyzer,Wall-mounted Ozone Gas Analyzer, OEM/ODM services
